Filter Press, Low Pressure, 4 Unit

OFITE's Multi-Unit filter presses are perfect for lab environments when several tests must be run simultaneously. These units come complete with manifolds and all necessary air hoses and bleed-off valves. Suitable for laboratory use, OFITE Filter Presses have become the industry standard for low pressure/low temperature filtration testing.

Features

• Stainless steel test cell
• Suitable for lab use
• Conforms to API specifications

Specifications

• Maximum Pressure: 100 psi (690 kPa)
• Pressure Source: Any non-hazardous gas
• Number of Units: 4
• Filtration Area: 7.1 ± 0.1 in2 (4,580 ± 60 mm2)
• Filter Paper Size: 3.5” (9 cm)

Components

• #140-55: Filter Paper
• #141-00-C: Test Cell
• #141-00: Cell Body
• #141-01: Base Cap
• #141-02: Top Cap
• #141-04: Screen
• #141-05: Gasket, Neoprene
• #141-09: Threaded Insert with Set Screw
• #141-10: T-Screw
• #141-13: Air Hose, Low Pressure, 15"
• #141-19: Air Hose Adapter
• #141-22: Felt Filter
• #143-06: Safety Bleeder Valve
• #153-16: Graduated Cylinder
• #170-34: Needle Valve

Optional

• #141-15: Air Hose, Low Pressure, 6'
• #140-40-SP: Spare Parts Kit for #140-40
• #140-50-SP: Spare Parts Kit for #140-50
• #153-16: Graduated Cylinder, 25 mL × .2 mL
• #171-24-1: Nut for Pressure Fitting, Right-Hand Thread
• #171-24-2: Nipple for Pressure Fitting
• #170-36: Nitrogen Regulator with Gauges

Part Number

• #140-40
